Description
JET’s Air Compressors are ideal for general compressed air needs including machine shops, fabricating shops, auto motive service and body shops, fleet maintenance, woodworking shops, farm and general industrial applications. The cast iron pumps, ASME-certified tanks and industrial-duty motors are essential for reliable performance in these demanding environments. These tanks are CSA Certified and ASME-certified to meet strict testing and inspection standards.
- 175 psi maximum operating pressure for applications requiring higher air capacity and pressure
- 2-stage, cast iron pump design delivers higher pressure and increased air delivery
- ASME-certified tanks meet strict testing and inspection standards
- Critical components of the crankcase, crankshaft and cylinders are cast iron for reliability and durability in demanding industrial environments
- Precision machined aluminum head and valve system dissipates heat quicker for long-lasting performance
- Head and valve plate design features high temperature O-rings for leak proof, high-pressure sealing
- 2-piece connecting rods include needle bearings for high load capabilities and long life
- Ductile iron crankshaft is machined and balanced for smooth, low vibration operation
- Pistons feature a 3-piece ring set that prevents oil from entering the air stream
- Fully enclosed metal belt guard assures safe operation
Features
| Item Weight | 540 |
| Tank Material | Cast Iron |
| Compressor/Air Tool Features | Automatic Shut-off,Automatic Start/Stop,Combo Kit,Tank Pressure Gauge,Universal Quick Connectors |
| Power Type | Corded Electric |
| Decibel Rating (Outdoor) | 87 dBA |
| Horsepower (hp) | 7.5 hp |
| Voltage (volts) | 230 |
| Compressor Tank Capacity (Gallons) | 80 |
| Included | No additional components or accessories are included |
| Compressor Volume Rating | Standard |
| Voltage (v) | 230v |
| Product Weight (lb.) | 540 |
| Application Use | Air Brushing,Blow Cleaning,Bolting/Wrenching,Brad Nailing/Stapling,Cutting,Drilling,Finish Nailing,Framing Nailing,Grinding,HVLP Painting,Hobby Nailing,Hobby Painting,Inflation,Roof Nailing,Sanding,Spraying,Surface Prep |
| Amperage (amps) | 31 |
| Tank Style | Vertical |
| Tools Product Type | Air Compressor Kit |
| Maximum Pressure (psi) | 175 |
| Portable | No |
| Air Delivery SCFM @ 90PSI | 25.1 |
| Compressor Tank Capacity (Gal.) | 80 Gal. |
| Lubrication Type | Oil-Lubricated |
| Returnable | 180-Day |
| Compressor Type | Garage & Industrial |
| Air Delivery SCFM @ 40PSI | 27.1 |
| Stage Count | Two Stage |
| Power Source | Electric |
| Product Depth (in.) | 42 |
| Product Height (in.) | 78 |
| Product Width (in.) | 42 |
| Manufacturer Warranty | 3 Year |
| Certifications and Listings | CSA Certified,ETL Listed,UL Listed |
Reviews
There are no reviews yet.
